Description

DALI is figure signal, different from analog signal, 1010 signal can realize non disturbance control,no distortion causes by long distance voltage drop. So there is no disturbance even though DALI figure signal control cable and power line use one cable spool.DALI signal is two-way transmission, it not only can transfer control order to forwarder,but also feed back to the system the information of ballast and tubes’s condition, fault message, switch, and the actual luminace.

• Light sensitive

  when outside is bright. the illuminace around panel over 600Lux. the panel will reduce to 5% luminace automatically.
  outside light is weak,the illuminace around panel lower than 600Lux, the panel will automatically raise illuminace to 600Lux and keep to around 600Lux always.

• Light sentive + human sentive

  Panel in standby status. When outside is bright, the illuminace around panel over 600Lux, panel autamtically switch on while human body enter the detection area. Light 5% illuminace. Panel automatically switch off after human leaves detection area a which(optional in 60m/45m/30m/20m/15m/10m/5m/3m/2m/ 1m/30s to switch off after leaving detection area)
  Panel in standby status. When outside light is weak, the illuminace around the panel lower than 600Lux, panel automatically switch on while human body enter the detection area. Automatically reduce lumens when over 600lux around the panel and Keep the illuminace around to 600Lux always.
