Connector
Triangular application
Cross application
Right angle application
Basic parameters
| Rated voltage： | 12~24v |
| Rated current： | <4A |
| working environment： | moisture-proof ventilation -20 ~ 60 degrees environment |
| Temperature resistance： | -40-160℃ |
Wire joint
LD-XC-JXD-D2
LD-XC-JXD-H2
LD-XC-JXD-T2
Base parameters
| Shell： | Polycarbonate |
| Contact conductor： | high-precision pure copper |
| Rated voltage： | 0-36V |
| Rated current： | 9A |
| Flame retardant rating: | accord with UL-94-V0 |
LED Quick connector-10mm
LD-SE-DJ-N10BB-2-1
LD-SE-DJ-N10XB-2-1
LD-SE-N10BB-2-1
LD-SE-N10XB-2-1
LD-TG-N10BB-2-1
LD-TG-N10XB-2-1
Base parameters
| Shell: | Polycarbonate |
| Contact chip: | Environmentally hardware material,high-precision copper |
| Rated voltage： | 0-36V |
| Rated current： | 5A |
FE19C-P8-G1 27ZRG27ZB8x 24V120S W10L05
Description
- Can achieve a variety of colors including white, and improve color index and consistency for white lights.
- Integrated package solution for more uniform and consistent light mixing.
Parameters
- Size:5018±10mm
- Cutting unit:100±1mm
- Power:19.2W/m
- Voltage:DC24V
- Led Qty:120LEDs/M
- PCB:12.5mm
- IP:IP68
| LUMENS PER METER | |||||
| Product No. | FE19C-P8-G1 27ZRG27ZB8x 24V120S W10L05 | ||||
| 2400K | 264lm | ||||
| 2700K | 272lm | ||||
| 3000K | 289lm | ||||
| 4000K | 306lm | ||||
| 6000K | 323lm | ||||
| Red |
111lm |
||||
| Green |
281lm |
||||
| Blue |
60lm |
||||
| Product No. | Order Code |
| FE19C-P8-G1 27ZRG27ZB827 24V120S W10L05 | 931-8-99-0-000001 |
| 備注：‘*’=MTO(按訂單生產) | |
