Aluminum Profile
Aluminum Profile 1meters
913-01-1299-012
Aluminum Profile 2meters
913-01-1299-013
Basic parameters
| Material： | Aluminum alloy |
| Ohter： |
|
Bendable Fixed Clip
1 meters
913-01-0299-004
0.5 meters
913-01-0299-005
Basic parameters
| Material： | Aluminum alloy |
| Other： |
Connector
Intermediate connector
804-01-0078
connector with wire
804-01-0077
Basic parameters
| Material： | Copper with plastic |
Bracket
Bracket
701-0112-336
Basic parameters
| Material： | Aluminum alloy |
| Package： | Ten |
| Other： | With screws |
End cap kit
front outlet end cap
723-0507-068
end cap without hole
723-0507-067
end cap bottom outlet
723-0507-120
end cap side outlet
723-0507-119
Basic parameters
| Material： | Silicon glue |
| Other： |
|
FEN12CS-P7-G1 38XRGB 24V120S 0816L05
Description
- Seamless and uniform light output, dot free
- Bendable at vertical direction
- IP67 protection
- Robust housing with high quality silicon, UV proof for true outdoor application
- Easy installation with clips
- Cut-able for flexible application
Parameters
- Size:5050±5mm
- Cutting unit:50±2mm
- Power:12W/m
- Voltage:DC24V
- LED type:3838
- Led Qty:120LEDs/M
- CRI: >90
- IP:IP67
| LUMENS PER METER | |||||
| Product No. | FEN12CS-P7-G1 38XRGB 24V120S 0816L05 | ||||
| Red | 43lm | ||||
| Green | 122lm | ||||
| Blue | 26lm | ||||
| Product No. | Order Code |
| FEN12CS-P7-G1 38XRGB 24V120S 0816L05 | / |
| 備注：‘*’=MTO(按訂單生產(chǎn)) | |
